Hydraulic Floor Springs & Floor Hinges For Glass Entrance Doors

Code:SW-288

Performance Specification

  • - Max Open Degree 116°

  • - 90° HO or NHO

  • - Two Sections Speed Valve:

  • - Closing Speed: 90° - 20°

  • - Latching Speed: 20° - 0°

Code:SW-830

Performance Specification

  • Maximum door width:1100x2300mm

  • Max door weight:120kg

  • Openging angle:125°

  • Positioning angle:90° /115°

Code:SW-8300

Performance Specification

  • Door size:1100x2300mm

  • Max door weight: ≤120kg

  • Openging angle:125°

  • Positioning angle:90° /115°

Code:SW-9500

Performance Specification

  • Maximum door width:1100x2300mm

  • Max door weight: ≤250kg

  • Openging angle:125°

  • Positioning angle:90° /115°

Code:SW-80

Performance Specification

  • Maximum door width: ≤1500mm

  • Max door weight: ≤300kg

  • Openging angle:180°

  • Positioning angle:90° /180° /360°

Code:-2400

Performance Specification

  • Door size:1300x2400mm

  • Max door weight:200kg

  • Openging angle:125°

  • Positioning angle:90° /115°

Code:SW-75

Performance Specification

  • Maximum door width: ≤1200mm

  • Max door weight: ≤150kg

  • Openging angle:180°

  • Positioning angle:90° /180° /360°

Code:SW-84

Performance Specification

  • Door size:1100x2300mm

  • Max door weight:130kg

  • Openging angle:125°

  • Positioning angle:90° /115°

Code:SW-818

Performance Specification

  • Door size:1100x2300mm

  • Max door weight:120kg

  • Openging angle:125°

  • Positioning angle:90° /115°

Code:SW-68

Performance Specification

  • Door size:1000×2200mm

  • Max door weight:100kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-220D

Performance Specification

  • Door size:1000×2100mm

  • Max door weight:100kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-220C

Performance Specification

  • Door size:900×2100mm

  • Max door weight:90kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-1400

Performance Specification

  • Maximum door width: ≤1250mm

  • Max door weight: ≤180kg

  • Opening angle:125°

  • Positioning angle:90°

Code:SW-220B

Performance Specification

  • Door size:900×2100mm

  • Max door weight:80kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-28

Performance Specification

  • Door size:1000×2100mm

  • Max door weight:90kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-7315

Performance Specification

  • Maximum door width: ≤1100mm

  • Max door weight: ≤110kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-65

Performance Specification

  • Door size:1000×2200mm

  • Max door weight:100kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-7300

Performance Specification

  • Maximum door width:1000×1300mm

  • Max door weight: ≤120kg or 150kg

  • Opening angle:125°

  • Positioning angle:90° /115°

Code:SW-102

Performance Specification

  • Bearing: 100kg

  • Suitable for door wide: ≤1000mm

  • Opening angle: 90° positioning, bidirectional opening

  • Closing Speed: 90° – 15° / Latching Speed: 15° – 0°

Code:SW-103

Performance Specification

  • Bearing: 80kg

  • 90° positioning, bidirectional opening

  • Two Sections Speed Valve:

  • Closing Speed: 90° – 15°

  • Latching Speed: 15° – 0°

  • Suitable for door width: 700-1000mm

KFC door shaft

Performance Specification

  • Main material: Cast iron + Cast aluminum

  • Surface treatment: wire drawing

  • Maximum door width: 1000mm

  • Maximum load: Small (30kg-100kg)，Large(30kg-120kg)

  • Scope of application: plastic steel door, wooden door,

  • 8-12mm tempered glass door

  • Main function: The maximum opening of the door is 170°
